Nitrogen Flow Meters - Acrylic, Brass Fittings, Valve Included

This AcrylicFlow Meter with Valve has a Dual Direct Reading Scale with yellow backing for easy viewing of Nitrogen flow values. Viton® Seals, 3/8" FNPT and Brass End fittings are standard. The float/guide material is 316 Stainless Steel. This Flow Meter is designed for panel mounting and can handle a Maximum Flow Rate of 575 LPM (21 SCFM).
  • Yellow Backed Scales in English or Metric Measures
  • Panel Mount
  • No Valve
  • Simple Dis-assembly and Assembly for Cleaning
  • Stable, Easy to Read Float
  • Optional scales can be developed for diverse low flow conditions, facilitating OEM applications
  • Valve Included
Specifications 6A02 Acrylic Flow Meters
Accuracy: +/- 5% of Full Scale reading
Maximum Temperature:
54° C (130° F)
Maximum Pressure:
6.89 bars (100 psig)
Maximum Flow Rate:
575 LPM (20.5 SCFM)
Body:
Optical, Clear, Cast Acrylic
Float & Guide
316 Stainless Steel
O-Rings:
Viton®
Connections: Brass 3/8" NPT Female Connections
Valve Parts: Brass

Usually Ships in 2 to 3 Weeks
Item #Item DescriptionItem PriceSubtotalQty
6A0209BV-NCNitrogen Flow Meter 270 LPM (9.5 SCFM) - Acrylic, Brass Fittings, Valve Included $205.00 $0.00
6A0211BV-NCNitrogen Flow Meter 575 LPM (21 SCFM) - Acrylic, Brass Fittings, Valve Included (6A0211BV-NC) $205.00 $0.00
