Available for multiple flow rates, this Acrylic Flow Meter has a Dual Direct Reading Scale with yellow backing for easy viewing of Water flow values. Viton® Seals, 1/8" FNPT and Stainless Steel End fittings are standard. The float material varies based on the metering range (316 SS, Carboloy, Glass). Available for metering flow rates from 20 mL/min (0.3 GPH) to 1400 mL/min (22 GPH).
| Item# |
Item Name |
Item Price |
Qty |
Add |
| 6A0105SN-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 100.0 mL/Min ; 1.5 Gal/Hr Water, Carboloy Float, No Valve |
|
|
|
| 6A0105SV-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 100.0 mL/Min ; 1.5 Gal/Hr Water, Carboloy Float, Valve |
|
|
|
| 6A0113SN-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 1400.0 mL/Min ; 22.0 Gal/Hr Water, 316 Stainless Steel Float, No Valve |
|
|
|
| 6A0113SV-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 1400.0 mL/Min ; 22.0 Gal/Hr Water, 316 Stainless Steel Float, Valve |
|
|
|
| 6A0107SN-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 175.0 mL/Min ; 2.75 Gal/Hr Water, Glass Float, No Valve |
|
|
|
| 6A0107SV-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 175.0 mL/Min ; 2.75Gal/Hr Water, Glass Float, Valve |
|
|
|
| 6A0101SN-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 20.0 mL/Min ; 0.3 Gal/Hr SCFH Water, Glass Float, No Valve |
|
|
|
| 6A0101SV-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 20.0 mL/Min ; 0.3 Gal/Hr Water, Glass Float, Valve |
|
|
|
| 6A0109SN-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 450.0 mL/Min ; 6.5 Gal/Hr Water, 316 Stainless Steel Float, No Valve |
|
|
|
| 6A0109SV-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 450.0 mL/Min ; 6.5 Gal/Hr Water, 316 Stainless Steel Float, Valve |
|
|
|
| 6A0103SN-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 70.0 mL/Min ; 1.1 Gal/Hr Water, 316 Stainless Steel Float, No Valve |
|
|
|
| 6A0103SV-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 70.0 mL/Min ; 1.1 Gal/Hr Water, 316 Stainless Steel Float, Valve |
|
|
|
| 6A0111SN-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 700.0 mL/Min ; 11.0 Gal/Hr Water, Carboloy Float, No Valve |
|
|
|
| 6A0111SV-WA |
Water Flow Meter - Acrylic, Stainless Fittings - 700.0 mL/Min ; 11.0 Gal/Hr Water, Carboloy Float, Valve |
|
|
|
| Check the items you wish to purchase, then click
|
|
Features:
- Yellow Backed Scales in English or Metric Measures
- Customer Convertible Panel to Partial or Full In-Line Mounted Configurations
- Available With or Without Built-in Low Hysteresis Needle Valves
- Simple Dis-assembly and Assembly for Cleaning
- Stable, Easy to Read Float
Technical Specs:
-
- Specifications
-
| -
-
| -
- 6A01 Acrylic Flow Meters
-
| -
- Accuracy:
-
| -
-
| -
- +/- 5% of Full Scale reading
-
| -
- Maximum Temperature:
-
| -
-
| -
- 65° C (150° F)
-
| -
- Maximum Pressure:
-
| -
-
| -
- 6.9 bars (100 psig)
-
| -
- Meter Block:
-
| -
-
| -
- Clear, Machined Acrylic
-
| -
- Float Materials:
-
| -
-
| -
- Black Glass, Stainless Steel, Tungsten Carbide (Carboloy®)
-
| -
- O-Ring Seals:
-
| -
-
| -
- Viton®
-
| -
- Fittings:
-
| -
-
| -
- Brass or 316 Stainless Steel 1/8" NPT Female Connections, Built-in Needle Valves & Seal Plugs
-
|
