Available for multiple flow rates, this Acrylic Flow Meter has a Dual Direct Reading Scale with yellow backing for easy viewing of Helium flow values. Viton® Seals, 1/8" FNPT and Stainless Steel fittings are standard. The float material varies based on the metering range (316 SS, Carboloy, Glass). Available for metering flow rates from 2.0 LPM (4.0 SCFH) to 110 LPM (250 SCFH)
| Item# |
Item Name |
Item Price |
Qty |
Add |
| 6A0113SN-HA |
Helium Flow Meter - Acrylic, Stainless Fittings - 110.0 LPM/250.0 SCFH Helium, 316 Stainless Steel Float, No Valve |
|
|
|
| 6A0113SV-HA |
Helium Flow Meter - Acrylic, Stainless Fittings - 110.0 LPM/250.0 SCFH Helium, 316 Stainless Steel Float, Valve |
|
|
|
| 6A0107SV-HA |
Helium Flow Meter - Acrylic, Stainless Fittings - 18.0 LPM/40.0 SCFH Helium, Glass Float, Valve |
|
|
|
| 6A0101SN-HA |
Helium Flow Meter - Acrylic, Stainless Fittings - 2.0 LPM/4.0 SCFH Helium, Glass Float, No Valve |
|
|
|
| 6A0101SV-HA |
Helium Flow Meter - Acrylic, Stainless Fittings - 2.0 LPM/4.0 SCFH Helium, Glass Float, Valve |
|
|
|
| 6A0109SN-HA |
Helium Flow Meter - Acrylic, Stainless Fittings - 35.0 LPM/70.0 SCFH Helium, 316 Stainless Steel Float, No Valve |
|
|
|
| 6A0109SV-HA |
Helium Flow Meter - Acrylic, Stainless Fittings - 35.0 LPM/70.0 SCFH Helium, 316 Stainless Steel Float, Valve |
|
|
|
| 6A0103SN-HA |
Helium Flow Meter - Acrylic, Stainless Fittings - 5.0 LPM/10.0 SCFH Helium, 316 Stainless Steel Float, No Valve |
|
|
|
| 6A0103SV-HA |
Helium Flow Meter - Acrylic, Stainless Fittings - 5.0 LPM/10.0 SCFH Helium, 316 Stainless Steel Float, Valve |
|
|
|
| 6A0111SN-HA |
Helium Flow Meter - Acrylic, Stainless Fittings - 55.0 LPM/110.0 SCFH Helium, Carboloy Float, No Valve |
|
|
|
| 6A0111SV-HA |
Helium Flow Meter - Acrylic, Stainless Fittings - 55.0 LPM/110.0 SCFH Helium, Carboloy Float, Valve |
|
|
|
| 6A0105SN-HA |
Helium Flow Meter - Acrylic, Stainless Fittings - 8.0 LPM/17.0 SCFH Helium, Carboloy Float, No Valve |
|
|
|
| 6A0105SV-HA |
Helium Flow Meter - Acrylic, Stainless Fittings - 8.0 LPM/17.0 SCFH Helium, Carboloy Float, Valve |
|
|
|
| 6A0107SN-HA |
Helium Flow Meter - Acrylic, Stainless Fittings -18.0 LPM/40.0 SCFH Helium, Glass Float, No Valve |
|
|
|
| Check the items you wish to purchase, then click
|
|
Features:
- Yellow Backed Scales in English or Metric Measures
- Customer Convertible Panel to Partial or Full In-Line Mounted Configurations
- Available With or Without Built-in Low Hysteresis Needle Valves
- Simple Dis-assembly and Assembly for Cleaning
- Stable, Easy to Read Float
Technical Specs:
-
- Specifications
-
| -
-
| -
- 6A01 Acrylic Flow Meters
-
| -
- Accuracy:
-
| -
-
| -
- +/- 5% of Full Scale reading
-
| -
- Maximum Temperature:
-
| -
-
| -
- 65° C (150° F)
-
| -
- Maximum Pressure:
-
| -
-
| -
- 6.9 bars (100 psig)
-
| -
- Meter Block:
-
| -
-
| -
- Clear, Machined Acrylic
-
| -
- Float Materials:
-
| -
-
| -
- Black Glass, Stainless Steel, Tungsten Carbide (Carboloy®)
-
| -
- O-Ring Seals:
-
| -
-
| -
- Viton®
-
| -
- Fittings:
-
| -
-
| -
- Brass or 316 Stainless Steel 1/8" NPT Female Connections, Built-in Needle Valves & Seal Plugs
-
|
