Dakota

This Acrylic Flowmeter with Valve has a Dual Direct Reading Scale with yellow backing for easy viewing of Nitrogen flow values. Viton^® Seals, 3/4" FNPT and Polypropylene End fittings are standard. The float/guide material is 316 Stainless Steel. This Flowmeter is designed for inline mounting and can handle a Maximum Flow Rate of 2200 LPM (77.5 SCFM).

This Acrylic Flow Meter with Valve has a Dual Direct Reading Scale with yellow backing for easy viewing of Carbon Dioxide (CO2) flow values. Viton^® Seals, 3/8" FNPT and Brass End fittings are standard. The float/guide material is 316 Stainless Steel. This Flow Meter is designed for panel mounting and can handle a Maximum Flow Rate of 475LPM (17 SCFM).

Cable with 9-pin D-connector for GM series Mass Flow Meter, 0-5 Vdc, 3 feet length (6ACBL-D5)

This Acrylic Flow Meter has a Dual Direct Reading Scale with yellow backing for easy viewing of H20 flow values. Viton^® Seals, 3/8" FNPT and Brass End fittings are standard. The float/guide material is 316 Stainless Steel. This Flow Meter is designed for panel mounting and can handle a Maximum Flow Rate of 15 LPM (4 GPM). No Valve.

This Acrylic Flowmeter has a Dual Direct Reading Scale with yellow backing for easy viewing of Carbon Dioxide (CO2) flow values. Viton^® Seals, 3/4" FNPT and Polypropylene End fittings are standard. The float/guide material is 316 Stainless Steel. This Flowmeter is designed for inline mounting and can handle a Maximum Flow Rate of 1800 LPM (62.5 SCFM). No Valve.

Female 9-Pin D Connector Cab;e with 6 feet length (6ACBLDP9-6) for Pulse Width Modulated Driver Module

This Acrylic Flow Meter with Valve has a Dual Direct Reading Scale with yellow backing for easy viewing of H20 flow values. Viton^® Seals, 3/8" FNPT and Brass End fittings are standard. The float/guide material is 316 Stainless Steel. This Flow Meter is designed for panel mounting and can handle a Maximum Flow Rate of 15 LPM (4 GPM).

This Acrylic Flowmeter with Valve has a Dual Direct Reading Scale with yellow backing for easy viewing of Carbon Dioxide (CO2) flow values. Viton^® Seals, 3/4" FNPT and Polypropylene End fittings are standard. The float/guide material is 316 Stainless Steel. This Flowmeter is designed for inline mounting and can handle a Maximum Flow Rate of 1800 LPM (62.5 SCFM).

Stepping Motor Valve 9-Pin D-connector cable , Female, Unterminated Ends, 3 feet length

This Acrylic Flowmeter has a Dual Direct Reading Scale with yellow backing for easy viewing of H20 flow values. Viton^® Seals, 3/4" FNPT and Polypropylene End fittings are standard. The float/guide material is 316 Stainless Steel. This Flowmeter is designed for inline mounting and can handle a Maximum Flow Rate of 55 LPM (14.5 GPM). No Valve.

Available for multiple flow rates, this Acrylic Flow Meter has a Dual Direct Reading Scale with yellow backing for easy viewing of Helium flow values. Viton Seals, 1/8" FNPT and Brass End fittings are standard. The float material varies based on the metering range (316 SS, Carboloy, Glass). Available for metering flow rates from 2.0 LPM (4.0 SCFH) to 110 LPM (250 SCFH).

Available for multiple flow rates, this Acrylic Flow Meter has a Dual Direct Reading Scale with yellow backing for easy viewing of Oxygen flow values. Viton Seals, 1/8" FNPT and Brass End fittings are standard. The float material varies based on the metering range (316 SS, Carboloy, Glass). Available for metering flow rates from 1.1 LPM (2.5 SCFH) to 45 LPM (90 SCFH).

This Acrylic Flowmeter with Valve has a Dual Direct Reading Scale with yellow backing for easy viewing of H20 flow values. Viton^® Seals, 3/4" FNPT and Polypropylene End fittings are standard. The float/guide material is 316 Stainless Steel. This Flowmeter is designed for inline mounting and can handle a Maximum Flow Rate of 55 LPM (14.5 GPM).

Made entirely of PTFE, PFA and PCTFE, the In-Line PTFE Flow Meter is excellent for high-purity applications or use with corrosive liquids. These meters feature chemically inert wetted components and a removable protective shield. Each meter is individually leak tested.

Dakota's Mass Flow Controllers are compact, self contained and easy to read. The rugged design and instrumentation grade accuracy provide versatile and economical means of flow control ideal in laboratory and industrial settings. The built-in electromagnetic valve allows the flow to be set to any desired flow rate within range of a particular model. Set points may be controlled either locally or remotely.

Available in flow ranges from 10 mL/min to 1000L/min relative to Nitrogen. Accuracy +/-1% full scale for models up to 100 Liters per minute.

Dakota's Mass Flow Controllers are compact, self contained and easy to read. The rugged design and instrumentation grade accuracy provide versatile and economical means of flow control ideal in laboratory and industrial settings. The built-in electromagnetic valve allows the flow to be set to any desired flow rate within range of a particular model. Set points may be controlled either locally or remotely.

Available in flow ranges from 10 mL/min to 1000L/min relative to Nitrogen. Accuracy +/-1% full scale for models up to 100 Liters per minute.

Dakota's Mass Flow Controllers are compact, self contained and easy to read. The rugged design and instrumentation grade accuracy provide versatile and economical means of flow control ideal in laboratory and industrial settings. The built-in electromagnetic valve allows the flow to be set to any desired flow rate within range of a particular model. Set points may be controlled either locally or remotely.

Available in flow ranges from 10 mL/min to 1000L/min relative to Nitrogen. Accuracy +/-1% full scale for models up to 100 Liters per minute.
